Standard Functions
| Flow Rate Control | Fixed Flow Rate by Onboard Potentiometer Variable Flow Rate by MAP Sensor Real Time Flow Rate Control by PWM Input |
| Troubleshooting | Error code reporting by onboard LED array Error code transmission by CAN bus |
| CAN Communication | System Voltage Current Draw Flow Rate Operating Temperature MAP Voltage PWM Duty Cycle |
Basic Operating Specifications
| Operating Voltage: | 7.0 to 17.5 volts DC (w/ Reverse Polarity Protection) |
| Pressure | 150psi Maximum |
| Flow Rate | Variable – From 400 l/h – 1,100 l/h |
| Current Draw – Dependent on Operating Conditions: | 5 amp minimum 100 amp maximum |
| Ambient Temperature Range: | -18°C to 70°C |
